The MoodLine WRGB1465 linear LED-module is a constant voltage LED assembly with built-in current controlled LED control circuits for long lifespan and uniform illumination.
The MoodLine WRGB1465 LED-module creates rich saturated colours and in combination with the high efficient warm-white LED’s really nice pastel colour tones.
Together with the LC6mk3 LED-driver special dimming modes, warm-dimming and tunable White options are available.
MoodLine WRGB1465 LED-module
Kenmerken
- 24VDC Contant Voltage LED-module
- 2500K 90CRI White + RGB Colours
- CCT-tuning from 6500 ~ 1400K
- LED-module for 24mm profile series
Technische specificaties
LED
| Colour | W + RGB |
| Colour temperature White | 2500K |
| Lumen output White | 665lm |
| Lumen outrput RGB | RED 94lm / Green 314lm / Blue 62lm |
| LED's per module lengte of 420mm | 60 |
Voeding
| Power | 24VDC |
| Consumption | White 6Watt / RGB 7.2Watt |
Bediening
| Recommended LED-driver | LC6mk3 LED-driver |
Materiaal
| Module length | 420mm |
| Cut length | 84mm |
| Module width | 21.7mm |
